Effects of applying cellulase and starch on the fermentation characteristics and microbial communities of Napier grass (Pennisetum purpureum Schum.) silage

Napier grass was cultivated in 2020 in an experimental trials field of VTR Bio-Tech (Doumen District, Zhuhai, Guangdong, China), located at 22°8ʹ19ʺ N, 113°14ʹ6ʺ E, and an average sea level of −7 m. This experimental area was within the subtropical marine climate zone, and the soil type was Alfisols (as defined by the United States Department of Agriculture); annual mean temperature was 22.3°C; average annual precipitation was 2,061.9 mm; average annual wind speed was 3.0 m/s; and average annual humidity 78.7%. The grass was harvested at the mature growth stage in April prior to chopping into lengths of 1–2 cm. The chemical composition of the raw material before ensiling is shown in Table 1. The chopped Napier grass was divided into 3 groups: no additive (control); added cellulase (Group 1); and added cellulase and starch (Group 2). Cellulase was from Guangdong VTR Bio-Tech and soluble starch (food ingredient grade) was purchased from Guangzhou Chemical Reagent Factory (Guangzhou, China). Cellulase and starch were dissolved in distilled water as appropriate and applied evenly to the chopped Napier grass by spraying at levels of 120 U/g and 2% fresh matter respectively; an equivalent volume of distilled water was applied to the control group. After mixing thoroughly, three silos were prepared for each group and each group was ensiled in triplicate at room temperature using 0.5 L laboratory scale glass silos (8 cm diameter × 16 cm height) sealed with lids. At day 30, the nine laboratory silos were opened, 300 g of silage was collected and sub-samples were treated as follows: samples for chemical composition analysis were oven-dried and ground subsequently prior to been tested, and the detail methods utilized were described as below; fresh samples for fermentation characteristics, microbial population and community analysis were collected and stored at −80°C until required.

At day 30, the sub-samples of silage were oven-dried at 65°C for 72 h and the DM contents calculated. Dried samples were ground and passed through a 1 mm mesh sieve and stored in sealed vinyl bags prior to chemical composition analysis. Crude protein (CP) was determined by the Kjeldahl method according to the procedure of the Association of Official Analytical Chemists (AOAC, 1990) [11] using a K9860 Kjeldahl Analyzer (Hanon Advanced Technology Group, Jinan, China). Acid detergent fiber (ADF) and neutral detergent fiber (NDF) were measured by the method of Van Soest [12] using an ANKOM 2000 Automated Fiber Analyzer (Ankom Technologies, Fairport, NY, USA). WSC content was measured using a modified anthrone procedure [13]. Concentrations of ash before and after fermentation were measured using AOAC method [11].

Silage acidity was determined using an AB 150 pH meter (Fisher Scientific International, Pittsburgh, PA, USA). Ammonia nitrogen (NH₃-N) was analyzed by the phenol-hypochlorite reaction method [14]. Flieg’s score was calculated from the formula given by Zhang et al. [15]. Lactic acid (LA) was determined by a high performance liquid chromatography (HPLC) system (Agilent HPLC 1260, Agilent Technologies, Santa Clara, CA, US) equipped with a UV detector (column: Agilent Hi-Plex H; mobile phase: 5 mmol/l H₂SO₄; flow rate: 0.7 ml/min; temperature: 55°C); acetic acid (AA), propionic acid (PA) and butyric acid (BA) were measured by gas chromatography (GC), the instrumental conditions were described according to Zhao et al. [16].

Microbial populations were determined via the spread-plate method [17]. Samples (10 g) were homogenized in sterile conical flasks with sterile water (90 mL) and shaken for 30 minutes at room temperature. Serial dilutions (1 ml of 10⁻⁴ to 10⁻⁷) were inoculated on the agar surface, spread evenly and counted after incubation. LAB were incubated on De Man, Rogosa and Sharpe agar at 37°C under anaerobic conditions and enumerated after 48 h. Escherichia coli were incubated on violet red bile agar and enumerated after 18 to 24 h at 37°C under aerobic conditions. Viable mold and yeast were incubated on potato dextrose agar and enumerated after 48 to 72 h at 28°C under aerobic conditions. The microbial population data were collected as colony forming units (CFU) and transformed to a logarithmic scale on a fresh matter basis.

Microbial community analysis was used to investigate changes in the diversity of bacteria during ensling. Briefly, total genome DNA was extracted from the silage samples using the cetyltrimethylammonium bromide method. DNA concentration and purity were monitored on 1% agarose gels, and based on this, the DNA was diluted to 1 ng/μL using sterile water. The distinct V3-V4 regions of 16S rRNA were amplified and subsequently sequenced on NovaSeq 6000 platform (Novogene, Beijing, China). After sequencing, effective tags were produced by removing the barcodes and primers using “Fast Length Adjustment of Short” reads (FLASH; Version 1.2.7, available as open source code at ccb.jhu.edu/software/FLASH/) [18] according to the “Quantitative Insights Into Microbial Ecology” (QIIME; Version 1.9.1, available at qiime.org/scripts/split_libraries_fastq.html) [19] quality controlled process. The effective tags were then clustered into operational taxonomic units (OTUs) at a 97% similarity level. According to the OTU results, alpha (Shannon, Simpson, Chao1 and coverage) and beta diversity (Principal component analysis [PCA]) were obtained using QIIME and R software (Version 2.15.3; R Foundation for Statistical Computing, Vienna, Austria), respectively.

The collected data were analyzed using the general linear model procedure in IBM SPSS Statistics for Windows, version 23.0 (IBM, Armonk, NY, USA). Duncan’s test was utilized for multiple comparisons and significant differences were declared when p < 0.05. Statistical analysis of microbial diversity including OTU analysis, alpha and beta diversity analysis were performed on the Novomagic platform (available at http://magic.novogene.com; Novogene, China).

The highest DM content was found in Group 2 although this was not significantly different from the control (p > 0.05; Table 1). The CP content of Group 2 was significantly lower than the control and cellulase treated groups (p = 0.030) which could due to increased protein degradation during the ensiling process. Normally, two phases are formed during the protein degradation stage of silage fermentation. At the onset of fermentation, plant proteases hydrolyze proteins to peptides and amino acids, and these are subsequently degraded into various compounds which are metabolized by microbial protease rather than LAB [20,21]. Proteolysis during ensiling is affected by various of factors such as pH [22], and the initial DM [23] and WSC contents of the forage species [24]. The lower CP content in Group 2 might due to the increased proteolysis activities after adding cellulase and starch during fermentation, but the specific synergy mechanism among them remained unknown till now. Tao et al. [25] also observed similar results in alfalfa when ensiled with sweet sorghum. Previous studies have demonstrated that cellulase application to silage materials can improve fermentation quality by decreasing the NDF and ADF contents during ensiling [26-28]. A similar trend was observed here with decreased amounts of NDF and ADF, possibly due to the enzymolysis and acid solubilization of cellulose, hemicellulose and lignin during fermentation [29]. Compared with the control and Group 1, this decrease was significantly greater in Group 2 following the combined addition of cellulase and starch (p < 0.05). Jones et al. [30] demonstrated that adding starch to rye silage increased the WSC content by 3%–4% after ensiling, thus improving the silage quality. Here, the residual WSC content of Group 2 was higher than Group 1 and the control (p < 0.05); an increase was also detected in Group 1, possibly due to the hydrolysis of starch during ensiling, although the effect was not significant (p > 0.05). No significant differences were found in ash contents of the three groups, however, when compared to raw materials prior to ensiling, the three groups showed numerically increases. It was in line with the results of Rahjerdi et al. [31] on amaranth-corn combination silage.

Fermented silage usually shows a decrease in pH (Table 2). Compared with the control, both additive groups showed a reduction in pH (p < 0.05). The ratio of NH₃-N to total nitrogen is a critical index that can indicate the extent of proteolysis during ensiling; NH₃-N is produced from protein decomposition in fresh ensiling materials by the activity of Clostridium spp. [32]. The NH₃-N content in silage is an indicator of silage fermentation quality; a high NH₃-N content indicates a lower fermentation quality. In this study, no significant difference was found between all the groups (p = 0.826). LA is the main acid product produced by LAB from sugar substrates during ensiling; a higher LA concentration reflects increased conversion efficiency from WSC. Compared with the control, the applications of cellulase or cellulase / starch both increased the LA concentration of the silage (p < 0.05); the highest value was found in Group 2. Hence, the application of cellulase alone, or combined with starch, could facilitate the availability of enough substrate for increased LA production by LAB. In addition, added starch, in combination with cellulase, improved the quality of the silage. Numerical, but not significant, increases (p > 0.05) in AA were also detected in control, Group 1 and Group 2. AA is produced by Enterobacteria and heterofermentative LAB and, to some extent, a higher content might relate to increased DM loss [33]. PA was only detected in the control group. BA is also an indicator of poor fermentation quality, and it can reflect the activity of unfavorable Clostridium spp. during silage fermentation. Silage with relatively high BA levels might also be less palatable to livestock [34]. A good-medium grade silage might contain 5–10 g/kg DM BA [4,35]. No BA was detected in all the groups of this study, indicating that the activity of Clostridium spp. was inhibited during fermentation, rendering the silage preserved. According to Jones et al. [36], the ratio of LA to AA can reflect the extent of homolactic and heterolactic fermentation during ensiling. The silage treated with additives was dominated by LA rather than AA, indicating that homolactic fermentation was the major pathway. In addition, Bolsen [34] showed that silage produced without additives, such as the control in this study, may be less palatable to cattle. The silage was be ranked into five grades based on Flieg’s score; the cellulase and starch group were ranked as ‘Good’ and the control group was ranked ‘Average’ (Table 2).

Overall, cellulase application improved silage quality while the combination of starch and cellulase improved the fermentation characteristics of the Napier grass silage.

It is known that LAB are the dominant microbes during silage fermentation once anaerobic conditions are established and under these conditions, the growth of some undesirable microorganisms can be inhibited by bacteriocins produced by certain strains of LAB [37]. So, to some extent, higher populations of LAB may lead to improved fermentation quality. The LAB populations were elevated in the silage from Group 1 and Group 2 although the differences were not significant (p = 0.573). The results suggested that the additions of cellulase and starch may promote the growth of LAB during ensiling, but further studies may be required to understand the optimum dosage. Spoilage organisms such as Escherichia coli, mold and yeast are additional indicators of poor fermentation. Yeast is one of the detrimental microorganisms in silage fermentation which can cause secondary fermentation. Mold growth is promoted by aerobic exposure, e.g., when silos are not sufficiently sealed, resulting in decreased fermentation quality. Table 3 shows that E. coli, mold and yeast were not detected in any group. This could be attributed to inhibition of adventitious microbes by the low pH under fermentation conditions.

The Shannon and Simpson indices reflect microbial community richness while chao 1 and ACE indicate microbial diversity; microbial community richness is inversely associated with diversity, e.g., as richness increases, the diversity decreases and vice versa [50]. The alpha diversity indices for each group are given in Table 4.

The coverage values for the silage samples were all > 0.999, indicating that the sequencing data were sufficiently large to cover the entire profile of the microbial community. The highest observed species ranged from 173 to 243, which was greater than values reported elsewhere [49]. However, the latter was obtained from the analysis of silage produced from different ensiling materials (Neolamarckia cadamba leaves) and fermentation duration. The cellulase treated group (Group 1) showed significant increases in the Shannon and Simpson indices (p < 0.05) and numerical decreases in Chao 1 and ACE (p > 0.05), indicating that added cellulase decreased microbial community richness but increased diversity to some extent in the Napier grass silage. The low pH value in cellulase treated group caused by higher LA production might be the main factor underlying affected microbial diversity [51]. And Zheng et al. [52] also stated that lower microbial community richness were related to the disappearance of some epiphytic bacteria due to their lower adaptability to the anaerobic condition and acidic environment during ensiling. Interestingly, the combined application of cellulase and starch (Group 2) gave significant increases in all indices (p < 0.05). This could be due to some unknown synergistic effect of cellulase and starch during ensiling which altered the diversity of the microbial community. A similar phenomenon was also obtained for silage produced from Neolamarckia cadamba leaves [49].

To further evaluate the differences in microbial communities between the samples from different groups, beta diversity analysis was performed using PCA (Fig. 3). The contribution of the two principal components to the total variance were 34.15% and 24.39%, respectively. Parvin et al. [53] showed that silage samples with different microbial communities tended to separate, while similar communities gathered together. Fig. 3 shows that the control, Group 1 and Group 2 formed three separate distributions, suggesting that the application of additives exerted an effect on the microbial community during ensiling. The three replicate results of the control group distributed more widely than the replicates from the additive groups suggesting that the microbial communities in Group 1 and Group 2 were more stable.

Fig. 3. Principal component analysis (PCA) of microbial community for Napier grass silage. Control, no additives; Group 1, added cellulase; Group 2, added cellulase and starch.

Download Original Figure

These results demonstrated that both additives exerted a positive effect on the microbial communities of Napier grass silage, while the variances may help to explain the differences in silage fermentation quality resulting from different treatments.
